Features:
1 、2-probe connectors to connect wide-band/multi-frequency convex, linear and
transvaginal probes to obtain quality image in any parts of the patient.
2、Extensive software packages including Abdomen, OB/GYN, Urology, Cardiology,
Small parts etc.,7 methods(GS,CRL,BPD,HC,AC,FL,LMP)provided for the measure of
fetus age and weight, the user could measure womb, left/right ovary, indometrium,
bladder, left/right kidney, prostate, left/right atrium, left/right ventricle, valve and cardium,
etc. Report Page available.
3、Up to 3-6 obstetric measurement methods available or the user could define it by
himself for specific clinical requirements.
4、In single B mode, enlarge the selected area by pressing down the key Zoom In.. The
Enlarged area will be automatically optimized or have a Picture-in-Picture display.
5、Cineloop: up to 200 frames, in the meantime, dozens of images could be permanently
saved so that typical diseases could be gathered for further study in the future.
6、6-segment slider TGC and overall gain adjustment.
7、Laser printer applicable to print out the OB/GYN, Urological,Cardiological images and
reports for lowering down hospital’s cost involved.
8、USB ports available to transfer the image or relevant data to computer. USB flash disk
connectible.
9、Upgradable software and biopsy acupuncture functions. To freeze or defreeze the
images by pressing down footswitch
- Video gastroscope
- Video colonoscope
- Digital colposcope imaging system
- Hysteroscopy diagnosis system
- Infrared galactophore diagnoses system
- Monitor
- ECG machine
- ECG workstation
- Transcranial Doppler
- Electroencephalograph (EEG)
- Holter ambulatory ECG analysis system
- Hematology analyzer
- Chemistry analyzer
- Urine Analyzer
- Blood coagulation analyzer
- Electrolyte Analyzer
- Sperm detecting analysis system
- Ultrasound scanner
- Ultrasonic image working system
- Endoscopic imaging workstation
- Color ultrasound scanner
Specification
Probe Electronic convex array, linear array, convex transvaginal probe
Frequency 2.0-10.0 MHz
Display Mode B, B/B, B/M, M
Gray Scales 256
Monitor 10” SVGA
Resolution Lateral(horizontal) Depth≤2mm; Axial(vertical) Depth≤1mm
Max. Measurement
Depth
250mm
Zoom ×1.0，×1.2，×1.5, ×2.0
Body Marks 38 types indicating probe positions
Various
Measurement
Distance, area/perimeter, volume(ellipse method), angle, heart rate Time, EF
slope, fetal age , weight and EDCB
Extensive software
packages
Obstetrics ：GS、CRL、BPD、HC、AC、FL，and LMP measure EDD etc;
Gynecology ：Uterus、Left/Right Ovary、Endometrial Thickness;
Urology ：Bladder、Left/ Right Kidney、Prostate;
Cardiology ：Left Ventricle 、Left Ventricle、Left Atrium、 Mitral Valve、Pulmonary Valve
Character
Date, week, time, probe frequency, frame rate, ID No., doctor name, hospital name,
annotation, value, body mark, probe position, full-screen edit, character note etc.
Obstetrics, gynecology, urology, cardiology’s report generated automatically
Standard
Configuration
Main unit (1 pc),high-density multi-frequency electronic convex array probe(1 pc)
Dimensions 380mm(width) ×335mm (height) ×465mm (depth)
Weight: Approx. 12kg
