Light Source: 6V 10W, halogen lamp of more than 2000 hours’ life time

Spectrometer: interference filter.

Wavelength: 340nm、380nm、405nm、505nm、546nm、578nm、620nm, and one wavelength free.

CML precision: ±2nm

FWHM: ≤10nm

Stray light：≤0.5%(absorbance≥2.5)

Absorbance range: -0.214～3.000

Absorbance linearity: ±1%

Absorbance repeatability: ±0.001

Absorbance resolution: 0.0001

Precision: ≤1.0﹪

Carry over: ≤1%

Temperature: 25℃、30℃、37℃,±0.3℃

Flow cell：permanent quartz flow cell, minimal volume is 32μL, and disposable flow cell is selectable

Sampling system: pressure auto releasing pumps ensure the accuracy of suction volume

Operational system: VISTA、Windows XP、Windows2000

Memory Capacity: 512M

Hard disk: DOM disc resistant form vibrate, auto save and recover results

Test Method: End point,Fixed time,Kinetic,Factor,Muli-standards,Bichromatic,Dual wavelengths

Parameter Setting: Patients’ profile and calculated item can be set easily

Absoption volume: 200μL～3000μL

Sample volume: 10μL～50μL

Reaction curve: real time display the reaction curve

QC: auto draw the QC figure

Reagent: Open reagent system
