Sample/Reagent/Stirrer system

Sample volume:2μL～30μL，step by 0.1μL

Sample disc: 60 positions for primary tubes and secondary cups

Reagent volume:20μL～300μL, step by 1μL

Reagent disc: provide 60 reagent bottle positions

Reagent bottle: particular reagent bottle without dead volume

Reagent Cooling: continuous cooling system according to the principle of peltier

Probe: inner and outer walls are highly polished leads carry-over ＜0.1%, level detection and

vertical and horizontal collision protection

Stirrer: paddle stirrer coated with Teflon, stir immediately after the sample was added in.

Water consume: ＜1.5L/hour

Carry over: Optimized item test sequence and reinforced washing process, lower the carry over and

avoid probe being clotted

Power/ Dimension

Voltage: AC 85V～264V, 55Hz±8Hz, Auto adapt according to the input voltage

Power Consume: ≤350VA

Dimension: 850mm×650mm×1067mm（L×W×H）

Net weight: 90Kg

System function

Throughput: up to 225 tests/Hour(not including ISE tests)

Test Method: End point, Fixed time, Kinetic

Test Sequence: Discrete, Random access, STAT can be inserted at any time. Test sequence can be

sorted by samples or items

Spectrometer: enclosed array of spectrometer and photodiodes, maintenance free.

Cuvette washing: auto wash the cuvettes through 8 segments washing pipe and continuous use them(optional)

Reaction detect: monitor 81 cuvettes’s reaction at the same time

Photometric process: the interval time between two consecutive photometric points are exactly the

same.

Pipeline system: pressure auto released pumps and double filters to protect pumps and valves

Gearing: plastic gear leads lower noise and accuracy of positioning of moving parts

Environmental resistance: resistant form dust and water vapor

Calibration/QC

Calibration type: single point linear、two points linear、multi-points linear、Logit-4P、Logit-5P、

Spline、Exponential 5P、Polynomial 5P, auto choose the best fittest calibration

curve.

QC type: real time QC、daily QC、day to day QC

QC chart: L-J、Cumulative sum check、Twin Plot

QC rule: Customized QC rule in order to adapt different item’s requirements

Operational system

Operational system: VISTA、Windows XP、Windows2000

Memory: auto save and recover the results

Report format: Customized report format

Status Check: real time check the working status of the analyzer
