Specifications

Test Method:  Dispersion light nephelometric analysis

Test Principle: The highest point on first order differentiation, Percentage analysis

Zero point correction: Auto track the zero point, eliminate the effect of sample and reagent

Wavelength: 470nm

Light Source:  Cold Lamp with high brightness and long lifetime

Detector: Unique dispersion light detector with high sensitivity and repeatability, immunized the effect on result of jaundice、hemolysis、chyle and turbidity on plasma

Test Channel: 4 channels,each channel is independent, one or more same or different items can be test simultaneously

Incubator: Provide 28 incubators for reagent and sample

Incubator Temperature:37±0.2℃

Measure trigger: Auto trigger the measurement through configured pipette

Item modify: easy to add or edit items, easy to set the items parameters

Calibration: single-point calibration; multipoint calibration; auto store and match with calibration curve

Quality control: Auto draw the QC figure

Reagent: Open reagent system

Reagent volume: ≤40μL

Sample volume: ≤40μL

Memory: Save more than 10000 samples results, and auto recover the results when  power is off during

Working condition

Repeatability: CV≤5%

Calculative item: S、％、PTR、INR，Fib can be get through PT, This leads to lower the cost of reagent

Printer:  Inner thermal printer，can be connected to external printer

Information edit: easy to input and edit the detail information of patients

Interface:  RS-232 serial port，can be connected to external printer and computer

Working Environment: Temperature：10℃～30℃；Humidity：20%RH-80%RH

Voltage: AC 85V～264V，Auto adapt according to the input voltage

Power :   ≤80W
