Test Method:  Dispersion light nephelometric analysis

Test Principle: The highest point on first order differentiation, Percentage analysis

Zero point correction: auto track the zero point, eliminate the interference of sample and reagent

Wavelength: 470nm

Light Source:  Cold Lamp with high brightness and long lifetime

Detector: unique Dispersion light detector with high sensitivity and repeatability, immunized the effect on result of jaundice、hemolysis、chyle and turbidity on plasma

Test Channel: each channel is independent, one or more，same or different items can be tested simultaneously

Incubator: Provide reagent and sample with stable incubator,

Incubator Temperature:37±0.2℃

Measure trigger: Auto trigger the measurement through configured pipette

Item modify: easy to add or edit items, easy to set the items parameters

Calibration: single-point calibration; multipoint calibration; auto store and match with calibration curve

Quality control: auto draw the quality figure

Reagent: Open reagent system

Reagent volume: ≤40μL

Sample volume: ≤40μL

Memory: Save more than 10000 samples results, and auto recovering the results when power is off during working .

Repeatability: CV≤5%

Calculative item: S、％、PTR、INR，Fib can be get through PT, This leads to lower the cost of reagent

Printer:  Inner thermal printer，can be connected to external printer

Information edit: easy to input and edit the detail information of patients

Interface:  RS-232 serial port，can be connected to external printer and computer

Working Environment: Temperature：10℃～30℃；Humidity：≤70%RH

Voltage: 85-264V，Auto adapt according to the input voltage

Power :   ≤80W
